Capacity: 2000, 1000, 500, 200, 100 kg
Accuracy: High precision 0.5 level, ±0.5%
Load sensing: High precision tension and pressure transducer,(multiple sensors can be installed at the same time – optional)
High resolution: 1/100000
Magnification: 24digit AD No period of zoom
Unit choose: N, KN, Kgf, Lbf
Test speed range Servo: 0.5~500 mm/min can set
Speed control accuracy: ±0.2% (0.5level )
Test effective width: 400 mm
Test stroke (including fixture): 800 mm
Overload setting protection function: When the set test force exceeds 10%, the system will automatically stop for protection
Protection function of stroke setting: Protection for upper and lower limit position of stroke
Motor: Servo motor AC Servo motor & servo drive controller
Power consumption: 0.5 kVA
Power: 1ø, 220 VAC, 50/60 Hz
Computer:
Hardware The supplied hardware specifications can be purchased from the original ACER brand or supplied by the customer
Special software: Refer to the software version of the computer measurement system
Volume: Host machine 65x55x220cm
Weight
Host machine: 200 kg
Work table: 100 kg
Standard accessories: Tension fixture 1 pair, a group of tools, a manual, a warranty.
Optional
Extensometer: Elongation extensometer(gauge:25,50,75,100mm)
Fixture: Can customer tensile/compression fixtures
