Lisun LSG-1200A Compact Goniophotometer (0.1~30,000lx, ±0.2°)
♦ LSG-1200A has included a dark case
♦ Test range of luminosity: 0.1~30,000lx
♦ Test accuracy of luminosity: Class A
♦ Test range of angle:
LSG-1200A:
Horizontal angle: -0°～360° (Automatic)
Vertical angle: -90°～+90°(Automatic)
♦ Test accuracy of angle: ±0.2°
♦ Angle interval:
Horizontal angle: 1°/5°/10°/15°/22.5°/30°/45°/90°
Vertical angle: 0.5°/2°/1.5°
♦ Measure the maximum size of lamps: diameter=180mm
♦ The distance between the tested lamp and detector is 316mm/1000mm
♦ Measure beam angle automatically: staple half intensity angle as well as 1/4 intensity angle, 3/4 intensity angle and 1/10 intensity angle which meets the special requirements.
♦ Meets the requirements of IEC, CIE and LM-79 standards
♦ Work power supply:
a) Power supply voltage: AC 220V±10%
b) Power frequency: 50Hz/60Hz
c) Power dissipation: 35VA
♦ Requirement of working environment:
a) Allowable working environmental temperature: 0℃～40℃
b) Best temperature for normal test: 25℃±5℃
c) Relative humidity: ≤65％R.H
