Lisun LSBCI-40 ລະບົບການທົດສອບການສີດປັດຈຸບັນຫຼາຍ (≥300mA)
System Configuration
1. Bulk Current Injection Host Machine
• Test current: ≥300mA
• Output impedance: 50Ω
• Voltage standing wave ratio: ≤1.2
2. Signal Source (Built-in Host Machine)
• Frequency: 9K~1GHz (Maximum can scalable up to 3GHz)
3. Power Amplifier (Built-in Host Machine)
• Maximum output power: 125W (Linear power)
4. Power Meter (Built-in Host Machine)
• Input frequency: 9KHz~1GHz
• Input power: -40dBm~+30dBm
5. Directional Coupler (Built-in Host Machine): Coupling 40dB
6. F-120-6A Current Injection Probe: Maximum input power 1000W
7. F-55 Current Monitoring Probe: Maximum input power 1000W
8. FCC-BCICF-1 Calibration Fixture for Current Injection Probe: Fixing fixture for flow injection probe
9. Artificial Power Network: Simulate actual line impedance
10. Software: Chinese and English software which support Win7, Win8 and Win10
11. Magenetic Shielding Room: SDR-4000B inside size is 4000*1200*1800mm (option, the size can be designed according to customer request)
