Test Level: IPX1, IPX2, IPX3, IPX4, IPX5, IPX6
Turntable diameter: 600mm
Turntable maximum load bearing: 50KG
Turntable lifting height: 550mm—1100mm
Turntable speed: 1 -5r/min（accurately adjustable）
Turntable tilt: 0°or15°(horizontal direction)
Turntable rotation: Always forward / Forward and reverse alternate / intermittent rotation
Flow adjustment method: Manual adjust
Test time: 0-999 min
IPX12 part – technical parameters
Drip size: 600*600mm
Drip aperture: ￠0.4mm
Distance between drip holes: 20*20 mm
Flow: IPX1=1mm/min；IPX2=3mm/min
Flow adjustment method: Manual adjust
Drip board lifting method: Can not lifting (fixed)
IPX34 part – technical parameters
Swing tube size: R600mm(Can be added with R400/R200mm swing tube)
Pendulum flow: IPX3=1.8L/min；IPX4=2.6L/min
Water jet aperture size: 0.4mm
Water spray aperture spacing: 50mm
Swing tube inner diameter: 15mm
Pendulum angle: 120º（IPX3），350º（IPX4）Or custom settings
Swing tube Swing speed: 240°back and forth 4S，720°back and forth 12S (precise control) or custom
IPX56 Technical Parameters
IPX5 Water jet aperture: ￠6.3mm
IPX6 Water jet aperture: ￠12.5mm
Water spray distance: 2.5m(the distance from the nozzle to the center of the turntable)
IPX5 Water spray flow: 12.5±0.625(L/min)
IPX6 Water spray flow: 100±5(L/min)
Flow adjustment method: manual adjust (Rotor flowmeter)
Spray gun fixing method: Mechanically fixed and can adjust the angle of the gun manually (if need to automatically swing the spray gun, please order JL-3456CA series)
Equipment power supply: 380V/Three-phase/50Hz （60Hz customizable）
Datasheet
Features
• The outer casing is made of high-quality steel plate, and the surface is painted with paint which is beautiful and durable. The inner box, the turntable, and the wading part are all made of SUS304 stainless steel plate to make sure that it will not rust after using for a long time. (Inner box sheet thickness: 1.2mm, can handle the water pressure)
• IPX12: The compressed air drying function can remove the excess water in the drip tank after the test to avoid long-term water accumulation and fouling. (User need to provide air compressor)
• IPX34: The driver for the swing pipe adopts high-quality servo stepping motor, the swinging speed and angle are precisely adjustable. There is no out-of-step problem (the risk of out-of-step: it will cause the swinging tube to malfunction, hitting the middle turntable shaft, causing equipment damage)
• IPX56: It is with monolithic structure. The sray gun direction is adjustable and can be fixed. The operator only need to start the test but no need to carry the spray gun
• The water supply line is equipped with a filter to filter impurities in the water to prevent nozzle clogging.
• The LED waterproof lighting is installed in the chamber, and there is a large observation window on the door to facilitate the observation of the test sample.
• The equipment equipped with a water tank for recycling water, no need building a professional waterproof test room. The water tank float valve in the water tank automatically controls the water inlet, and has high and low water level alarm monitoring to effectively prevent the pump from being damaged due to running out of water.
• The turntable uses a stepper motor, the speed can be set on the touch screen, and can control the forward and reverse rotation (suitable for the sample power-on test to prevent winding). • Touch screen control function: Directly select the waterproof level on the self-developed IPX waterproof level test operation interface. You can run test according to the waterproof rating conditions in the standard terms easily.
• Test sample input power: single-phase 220V/10A (other specifications can be customized)
• Equipment power supply frequency: Default is 50Hz and 60Hz is also available (It is very important to confirm us your grid power frequency)
