Internal dimensions (mm): 1000*2000*800
Overall dimensions (mm): 2700×1300×1900
Interior Volume (L): 1600
Temperature Range: Ambient ～ +60 ℃
Temperature Fluctuation: ± 0.5 ℃
Temperature Deviation: ± 2.0 ℃
Humidity Range: 95% ~ 98% RH
Salt Fog Deposition: 1～2ml / 80cm2 · h
Spray Type: Continuous / Periodic
Salt Fog Collected: Fog collector and fog measure cylinder
Air Preheating: Saturated air barrel
Spraying System: Atomizer tower and Spray nozzles
Controller: PID controller
Safety Device: Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection
Material: Glass fiber reinforced plastics
Standard Configuration: 6 round bars and 5 V-shaped grooves
Advantages
1. Controlled and Uniform Salt Fog Output: The chamber maintains a constant spray pressure of 83 kPa, achieving a salt fog deposition rate of 1–2 mL/80 cm²·h, fully aligned with ASTM B117 and ISO 9227 requirements. The optimized spray tower and quartz nozzles ensure uniform fog distribution across the entire test space, reducing deviation between sample positions and improving result consistency.
2. High-Accuracy Temperature and pH Stability: Test temperature is controlled at 35 ± 2 °C, with a fluctuation of ≤ ± 0.5 °C during continuous operation. The system supports salt solution pH control of 6.5–7.2 (NSS) and 3.1–3.3 (AASS/CASS). Integrated PT-100 Class A sensors (0.001 °C resolution) provide precise monitoring, ensuring stable and repeatable corrosion conditions throughout long-term tests.
3. Flexible Sample Capacity with Defined Load Performance: Standard V-groove and round-rod sample holders support adjustable specimen angles from 15° to 30°, allowing multiple samples to be tested simultaneously without shielding effects. The chamber accommodates different model volumes (e.g. 150 L to over 2000 L), enabling both small-batch R&D testing and high-throughput production validation.
4. Durable Construction for Long-Duration Corrosion Testing: The chamber interior is designed for continuous exposure to 5 % NaCl solution at elevated temperature and humidity without structural degradation. The inverted-V transparent lid effectively prevents condensate drip onto specimens, maintaining test validity over hundreds to thousands of operating hours and reducing maintenance intervention.
5. Efficient Operation with Built-In Safety Thresholds: Automated water replenishment and dry-burn protection stop operation when water levels fall below safe limits, preventing heater damage. The programmable controller stores up to 120 programs with 100 steps each, supports continuous or cyclic spraying, and logs temperature, spray duration, and deposition data in real time for traceable, audit-ready reports.
