Supported Devices: EEPROM, SPINAND/NORFlash, ParalleNAND/NORFlash, eMMC/eMCP, MCU, PIC, CPLD, FPGA...
Supported Packages: SOP, SSOP, TSOP, TQFP, QFN, WSON, SNT, WLCSP, BGA...
Supported File Formats: INTEL HEX, MOTOROLA HEX, TEK HEX, ASCII HEX, BINARY..
Supported Adapters: 2~8
Programming Performance:
+ eMMC: 43Mbyte/sec
+ SPI: 1.5Mbyte/sec
+ NAND: 6.0Mbyte/sec
Pin Drivers: 56~240(Universal)
Logic Pin Driver:
+ Signal Level: 1.65~6.5V
+ Signal Frequency: 0~75MHz
PowerDriver:
+ VCC/VIO: 1.65~6.5V
+ ICC/IIO: 400mA
+ VPP(VHH): VPP/VHH:1.5V~15.5V
+ IPP(IHH): 150mA
eMMCI/O:
+ Pin Drivers: 88
+ Signal Frequency: 100~200MHz
eMMCPower:
+ VCC: (500mA/1.7~3.6V)x4
+ VCCQ: (500mA/1.7~3.6V)x4
Dimensions: 405x115x75mm
Weight: 3.5kg
Power Supply: DC 5V
Standard Accessories:
SU-562A Main unit x 1
USBCable x 1
Power Cord (InputAC110~240V,OutputDC5V/500mA) x 1
Option adapter
SU-56A-SFLASH-BGA24-4x6B-4S
SU-56A-SFLASH-SOP8-150-4E
SU-56A-SFLASH-SOP8-207-4E
SU-56A-SFLASH-SOP16-300-4E
SU-56A-SFLASH-TSSOP8-4E 240
SU-56A-SFLASH-WSON8-2x3-4S
SU-56A-SFLASH-WSON8-5x6-4S
SU-56A-SFLASH-WSON8-6x8-4S
SU-56A-TO-AH-480 ADAPTER
SU-56A-TO-DIP48 ADAPTER
