U.P.H.: 3K (programming time < 8s)
*Operation
Repeatability:
+ X Axis ±0.02mm
+ R Axis ±0.067°
+ Z Axis ±0.02mm
Max. Stroke:
+ X axis 590mm
+ R axis 340°
+ Z axes 28mm
IC Pick & Place: Vacuum Nozzles
Device Detection: Vacuum Sensor
Dimension(Main Unit): 1280x600x1210(W/D/H)mm
Dimension with LED Alarm & Packing Modules: 2100x600x1720(W/D/H)mm
Weight: 200kg
* Position System:
Positioning: Mechanical Offset Correction
Device Size: 30 x 30mm (Max)
*Programming System:
Built-in Programmer: Leaper-56 Universal Programmer
Adapter No. : 1~36
PIN Driver: 48 Universal
IC Type Packages: MCU, NAND Flash, NOR Flash, SPI, EEPROM, EPROM, FPGA...
IC Packages: WLCSP, BGA, u-BGA, QFN, LQFP, MLP, SNT, WSON, TSSOP, SSOP, SOP...
File Format: INTEL HEX, MOTOROLA HEX, TEK HEX, ASCII HEX, BINARY....
Communication: USB 2.0
* Input Media:
Tube Input: 150mil, 207mil, 300mil, 330mil
Tube Output: 150mil, 207mil, 300mil, 330mil
Tape Input: Tape Width 12~24mm
Tape Output: Tape Width 8~32mm (Pressure self-sealing)
* Control System:
OS: Windows XP embed
Display: 17” LCD
Data Input: Keyboard/Mouse
* Power:
AC Input: AC 200V~245V, Single Phase 3-Wire
Frequency: 50/60Hz
Power Consumption: 450W
Air Pressure: 0.6MPa (~6.0kg/cm2)
Air Input: 32 L/Min.
