Basic Accuracy : R: 0.1%, L: 0.2%, C: 0.2%
Measurement Range (R) : 20mΩ to 10MΩ
Measurement Range (C) : 0.1pF to 10mF
Measurement Range (L) : 10nH to 1.0H
Test Frequency : 100Hz – 100kHz
Test Voltage : 0.2Vrms – 1.0Vrms
Over Voltage Protection (between test tips) : No
Resistance (R) : Yes
Capacitance (C) : Yes
Inductance (L) : Yes
Impedance (Z) : Yes
Dissipation Factor (D) : Yes
Quality Factor (Q) : Yes
Phase Angle (Ө) : Yes
Equivalent Series Resistance (ESR) : Yes
Direct Current Resistance (DCR) : Yes
Diode Check : Yes
LED Testing : No
Continuity : Yes
Sorting : Yes
Recording : Yes
Self Calibration : Yes
PC Connectivity : Yes (LCR Link1 Required)
Dimensions (L x W x H) : 151 x 19 x 15mm
Weight : 30g
Display : OLED 0.96″, 128 x 64 Resolution
Battery : 3.7V LiPO, 150mAH, Rechargeable
External Power Source : DC 5V, micro-B USB Connector
SMD Test Probe : Gold Plated (Ultra-Precise)
