Power Mode
Resolution: 0.01% - 0.1% of Full Scale
Energy Mode
Resolution: 0.01% - 0.1% of Full Scale
Pulse repetition rate Range: Single shot - 6 Hz (a)
Power Probe Mode (FIT-H)
Resolution: 0.5 ‰ (a)
General Operating Characteristics
Sensor Compatibility: Thermal sensors, OEM thermal sensors, FIT-H power probes, Photodiodes, Blink FR
Storage Temperature Range: -20 / +70 °C
Operating Temperature Range: +5 / +40 °C
Relative Humidity Range: 10 – 70 %
PC connectivity: USB
Sensor Head connectivity: DB15
Selectable Wavelengths: 1 nm resolution (b)
Dimensions: 170 H x 100 W x 36-50 D (mm)
Weight: 380 g
Display: 4.3” TFT LCD high brightness; 480 x 272 resolution; resistive touch screen; 96 H x 55 W mm
Battery: Built in rechargeable Li-Pol; 3.7 V, 3700 mAh
Battery charge time: 7-8 hours if not working; 15-20 hours if working
Battery run time: >9 hours in normal operations; >15 hours in stand-by display mode
Supplied battery charger: Input 100/240 Vac; 50/100 Hz; 5 Vdc; 1A; Charging current: 0.5 A;
(Plus2 may be charged through a PC USB port)
Electronics Characteristics
ADC sampling rate: 64 Hz – 192 Hz (c)
ADC resolution: 23 bit
Electrical accuracy: ± 0.5 %
Analog Output: 0.025 – 2 V (with 16 bit resolution; 0.0015% resolution)
Analog Output Accuracy: ± 0.1%; ± 2 mV relative to display
