TABLE DIMENSIONS
Side to Side: 48 in. (122 cm)
Front to Back : 48 in. (122 cm)
TEST CAPABILITIES
Max. Acceleration: 600g
Min. Pulse Duration: 2 msec (half sine)
Max. Velocity Change : 20 ft./sec (6.1 m/sec)
Pulse Waveforms : Half Sine; Trapezoidal; Terminal Peak Sawtooth* (*with Optional Programmers )
MAXIMUM PAYLOAD
Standard : 750 lbs. (340 kg)
Heavyweight option: 2500 lbs. (1135 kg)
MACHINE ENVELOPE DIMENSIONS
Height
Standard : 120 in. (305 cm)
Heavyweight : 129 in. (328 cm)
Side to Side: 84 in. (213 cm)
Front to Back: 51 in. (130 cm)
POWER REQUIREMENTS
Machine : 200 – 240 VAC/3Φ/50 – 60 Hz: 8 amp min.; 380 – 480 VAC/3Φ/50 – 60 Hz: 4 amp min.
Controller: 100 – 120 VAC/1Φ/50 – 60 Hz: 3 amp min.; 200 – 240 VAC/1Φ/50 – 60 Hz: 3 amp min.
PNEUMATIC REQUIREMENTS
Nitrogen: 2200 psi (152 bar)
Plant Air*: 90 psi (6.2 bar) *for Low Impulse Kit
