GENERAL DATA:
Electrolytic cell: PEM technology
H2 purity: >99.9995% (1)
Outlet pressure (bar): 8(115psi)
Max flow rate (cc/min): 180
Dimensions (LxWxH cm): 56x45x19
Net weight (kg) (water tank empty): 20
COMMUNICATION:
RS232: •
RS485: -
USB: -
SOFTWARE FUNCTIONS:
Parallel mode capability: •
Auto refill tank function: •
CONNECTIONS:
Hydrogen outlet: 1/8” Compression Fitting
Water: Quick release push-in fitting
WATER:
Quality : Deionized, ASTM II,<0.1µS
Internal tank capacity (L): 1.1
External tank capacity (L): 5 or 10
ELECTRICAL REQUIREMENTS:
Power supply voltage: 100-240V 50/60Hz
Max power consuption (W): 280
Fuse rating (A): 4
CONNECTIONS:
Hydrogen outlet : 1/8” Compression Fitting
Water : Quick release push-in fi tting
OPERATING CONDITIONS:
Temperature (°C): 5 to 35 (41° to 95°F)
Humidity (°C) (Max,non condensing): 80% at 25 (77°F)
Noise (dB): <25
IP rating: 20
(1) Referred to O2 , DewPoint < -50°C ; (2) Referred to O2 , DewPoint < -75°C
