Applicable Sensors: Strain gages, Strain-gage transducers
Input Channels: 4
Synchronous Measurement: Up to 4 units by 16 channels
Applicable Gage Resistance: Quarter bridge system (2-wire or 3-wire): 120 Ω; Half and full bridge systems: 120 Ω to 1000 Ω
Input Connectors: 37-pin D-sub connector
Bridge Power Supply: AC 2 V rms
Gage Factor: 2.00 fixed
Balance Adjustment: Resistance: Within ±2% (±10000 μm/m) ; Capacity: Within 5000 pF
Balance Adjustment Methods: Resistance: Pure electronic auto balance method ; Capacity: CST method (Automatic tracking)
Nonlinearity: Within ±0.1%FS
Measurement Range: 200, 500, 1000, 2000, 5000, 10000, 20000 μm/m, 7 steps. ; Accuracy: within ±0.5%FS
Frequency Response: DC to 200 Hz; Deviation: within ±10%
Sampling: Sampling Frequencies : Max. 10 kHz (Synchronous sampling of 4 units 16 channels)
LPF:
Transfer Characteristics : 2nd order Butterworth
Cutoff Frequency : 10, 30, 100 Hz, and FLAT -4 steps
Amplitude Ratio at Cutoff Point : -3±1 dB
Attenuation : -12±1 dB/oct.
A/D Resolution: 24 bits
Holding Setting Conditions: 0.7 A or less (13 VDC)
TEDS: Loading function from the TEDS sensor (Applicable input adaptors UI-10A and UI-11A) ; CH name writing function (For the manufacture ID: KYOWA only)
Interfaces: USB2.0 (Compliant to the High-Speed, USB3.0 port supported)
Stability:
Temperature
Zero point: within ±0.2 μm/m per ºC
Sensitivity: within ±0.05%/ºC
Time
Zero point: within ±1 μm/m/8h.
Sensitivity: within ±0.3%/8h.
Withstand Voltage
Operating Temperature/Humidity: 0 to 40ºC, 20 to 85%RH (Noncondensing)
Vibration Resistant: ±29.42 m/s2 (3 G), 5 to 200 Hz, (12 cycles for each axis, 10 minutes/cycle)
Power Supply: DC 11 to 16 V; Connector: RM12BRD-4PH (Hirose)
Current Consumption: 0.7 A or less (12 VDC)
Dimensions: 210 W x 35 H x 157.5 D mm (Excluding protrusions)
Weight: Approx. 700 g
