Insulation resistance
Test voltage	100V	250V	500V	1000V
Measuring range (Auto range)	4.000/40.00/ 200.0MΩ	4.000/40.00/400.0/2000MΩ
First Effective Measuring range	0.1~20MΩ	0.1~40MΩ	0.1~200MΩ	0.1~1000MΩ
Mid-scale value	5MΩ		50MΩ
Accuracy	\|±2%rdg±6dgt
Second effective measuring range lower	0~0.099MΩ
Second effective measuring range upper	20.01~ 200.0MΩ	40.01~ 2000MΩ	200.1~ 2000MΩ	1001~ 2000MΩ
Accuracy	\|±5%rdg±6dgt
Rated current	DC 1~1.2mA
Output short circuit current	1.5mA max
Ω/Continuity
Auto range	40.00/400.0Ω
Accuracy	\|±2%rdg±8dgt
Output Voltage on open circuit	5V±20%
Output short circuit current	DC 220±20mA
Fuse	Quick acting ceramic fuse 0.5A/600V (Ø6.35×32mm)
AC Voltage
Range	AC 20~600V (50/60Hz) DC -20~-600V/+20~+600V
Accuracy	\|±3%rdg±6dgt
General
Applicable standards	IEC 61010-1 CAT.III 600V, IEC 61557-1,2,4, IEC 61326-1 (EMC), IEC 60529 (IP40)
Dimensions / Weight	105(L) × 158(W) × 70(D)mm / 600g approx.
Power source	R6P×6 or LR6×6
Accessories	7150A (Remote control switch set), 9121 (Shoulder strap), R6P (AA)×6, Instruction Manual
Optional	7115 (Extension Probe), 8016 (Hook type prod), 8923 (Fuse [0.5A/600V]), 9089 (Carrying Case)

KYORITSU 3023 Digital Insulation / Continuity Tester
