Product Parameters
Supply voltage
AC 220V ± 10%
Power frequency
50Hz/60Hz ± 1%
Measuring range
Capacitance 5pF - 200pF
Relative capacitance 1.000~30.000
Dielectric dissipation factor 0.00001 ~100
DC Resistivity 2.5 MΩm~ 20 TΩm
Measurement accuracy
Capacitance ± (1% reading + 0.5pF)
Relative capacitance ± 1% reading
Dielectric dissipation factor ± (1% reading + 0.0001)
DC Resistivity ±10% reading
Resolving power
Capacitance 0.01pF
Relative capacitance 0.001
Dielectric dissipation factor 0.0001
Temperature range
0~125 ℃
Temperature measuring error
± 0.5 ℃
AC test voltage
500~ 2200V continuously adjustable Frequency 50Hz
DC test voltage
0~500V continuously adjustable
Consumption
100 W
Outline dimension
500*360*420mm
Total weight
22kg
