Range: 0 -> 0.5mm; 0mm -> 9999mm (resolution 0.01)
instantaneous velocity vector of sound: 1000 to 15000m/s (1m/s step)
Display delay: -10 to 1000mm
Probe delay: 0 to 200μs
Calibration mode: by material, by frequency or automatic 2-point calibration
Emitting pulse energy: 220 pF, nF.
Oscillating stamping mode: 50 ohms, 500 ohms (1000 ohms in TR mode)
Pulse Repeat Frequency (PRF) : 4 to 1000 Hz in 10 Hz . steps
Frequency range: 0.2 to one Mhz/ 0.5 to 4 Mhz/ 0.8 to 8MHz/ 2 to 20 MHz
Gain: 0 -> 110 dB, step selection: 0.5 / 1/2 / 6 / 12dB
Waveform: Full pulse, positive half wave, negative half wave and RF
Noise filter mode: 0 to 80% screen with 1% adjustment
Evaluation Ports: A and B carry Peak, Flank and Jflank . modes
Resolution: 0.01 (0 -> 99.99mm); 0.1 (100 -> 999.9mm); 1mm (> 1000mm)
DAC/TCG, JIS DAC functions are available on the machine
Integrate compute capabilities with AWS D1.1
Possibility to integrate additional DGS software (Optional)
Unit: mm or Inch
Over 14 hours of operation with Li-ion battery (6.6Ah)
Machine weight: 2.2kg (including battery)
Dimensions: 177 x 255 x 100mm
800 file storage including data and A-scan images that can be read, printed or exported to other peripherals
Connect to PC via RS232 . port
Connect monitor/projector via VGA port
Probe connection type: 2 x Lemo-1 (or 2x BNC as required)
Languages: English, German, French, Spanish, Italian, Portuguese, Dutch, Finnish, Norwegian, Swedish, Danish, Romanian, Czech, Slovak.
