KOMEG TST-1125D ຫ້ອງການຊ໊ອກຄວາມຮ້ອນ (1125L)

Volume: 1000L

Inner size: W 1500 mm*H 750 mm*D 800 mm

Exterior size: W 1700 mm*H 1785 mm*D 1900 mm (Not include machine protruding parts!)

Area: About 3.23m2；(Confirm after signing the contract)

Technical parameters

Test Conditions: Equipment cooling method: air-cooled

Measured at room temperature: + 25 ℃ with no load

Temperature range: -20℃ ～ +100℃

Temperature fluctuation: ±0.5℃

Temperature uniformity: ≤2.0℃

Temperature deviation: ≤±2.0℃

Temperature change rate:

Heating rate: -20℃～+100℃， Average 3℃/min；（no load）

Cooling rate: +100℃～-20℃， Average 1℃/min；（no load）

Maximum load: 50Kg LCD Panel, 250W heat compensation

Humidity range: 50～95%R.H

Temperature and humidity range: Humidity deviation, ±3.0％RH（＞75％RH）±5.0％RH（≤75％RH）

Humidity uniformity: ±3.0％RH（no load）

Humidity fluctuation: ±2.0％RH

Noise: ≤75(dB) （The noise detection device is measured 1m away from the equipment door）

Power source specification: 380V AC(±10%)

Three-phase line + protection ground, grounding resistance ≤ 4Ω .

Power frequency: 50±0.5Hz

Ground protection: Ground resistance ≦4Ω .

Drain connection: Pagoda connector plug φ10 inner diameter silicone hose

Note: Guide the condensed water out of the cabinet.

Power supply wiring:

1. Standard power cord: 3m

2. Customers should provide a dedicated fusion-free switch for the equipment.
