Volume: About 1500 L
Inner Size: W1500 mm × H1000 mm × D1000 mm
Outer Size: W1740 mm × H1540 mm × D1405 mm
(Not including the protruding part)
Tips: For external dimensions, please confirm the three-view drawings according to the final design.
Test Conditions
Equipment cooling method: Fresh air circulated type
Measured at room temperature +25 °C under no load.
Temperature and humidity performance measurement complies with IEC60068-3-5.
Sensors placed at the air outlet.
Temperature Range: RT +20 °C ~ +300 °C
Temperature Fluctuation: ±0.5 °C
Temperature Uniformity:
±2.0 °C (RT ~ +100 °C)
±3.0 °C (+100 °C ~ +200 °C)
±4.0 °C (+201 °C ~ +300 °C)
Temperature Change Rate:
Heating rate: RT +20 °C → +300 °C ≤ 95 min (no load)
Load Condition: Without load
Noise: ≤75 dB
(Measured 1 m away from the chamber door by noise detection device.)
Compliance with Test Standards:
GB-2423.2-89 (IEC68-2-2) — Test B: High Temperature Test
GJB360.8-87 (MIL-STD-202F) — High Temperature Life Test
GJB150.3 (MIL-STD-810D) — High Temperature Test
