Three-phase
Source:
Voltage:
3x 15...300 VAC
3 × 15... 520 VAC;
1 × 15.... 300 VDC
Step value: 1 V
Accuracy : ± 1 %
Current : 3 x 25 AAC; 1 x 32 ADC
Transformer specifications: 22,500 VA
Frequency : DC, 50 or 60 Hz 1)
Rectification : Six-pulse bridge circuit 3)
Protection : Overcurrent, short-circuit, overload,limitation of switch-on current
Regulation : Motor-controlled
Measurement:
Voltage : up to 540 VAC
Accuracy : < 0.2 %
Current : up to 110 AAC
Accuracy : < 0.1 %
Sampling rates : 500 Hz up to 10 kHz
Complete system:
Power supply : 3 x 400 VAC; 50/60 Hz; Discrete connections for supplying power to the control electronics and the power module separately
Connections : Industrial plug connectors
Housing: 19“ 18 U
Screen : High-resolution 3.5" screen
Operation : Jog wheel and 6 function keys
Display elements: 6 status LEDs, status signals screen,illuminated ring on the jog wheel
Interfaces: RJ 45 (Ethernet), USB-B
