Ratio Accuracy
Ratio 1 - 5000: 0.03 % (typical) / 0.1 % (guaranteed)
Ratio 5000 - 10000: 0.05 % (typical) / 0.2 % (guaranteed)
Phase Displacement
Resolution: 0.01 min
Accuracy: 1 min (typical) / 3 min (guaranteed)
Winding Resistance
Range: 0.1 - 100 Ω
Resolution: 1 mΩ
Accuracy: 0.05 % + 1 mΩ (typical) (guaranteed)
0.1 % + 1 mΩ (guaranteed)
Load Measurement
Range: 0~300VA
Resolution: 0.01VA
Voltage Measurement Input
Secondary Input Range: 0~300V
Max Knee point: 30KV
Secondary Input Accuracy: ±0.1%
Primary Input Range: 0~30V
Primary Input Accuracy: ±0.1%
Output
Output Voltage: 0 Vac to 120 Vac
Output Current: 0 A to 5 A (15 A peak)
Output Power: 0 VA to 450 VA (1500 VA peak)
Main Power Supply
Input Voltage: 176 Vac to 264 Vac @ 10A Max
Permissible Input Voltage: 120 Vdc to 370 Vdc @ 5A Max
Frequency: 50 / 60 Hz
Permissible Frequency: 47 Hz to 63 Hz
Connection: Standard AC socket 60320
Physical Dimensions
Size (W x H x D): 360 x 140 x 325mm
Weight: <8 kg (without accessories)
Environment Conditions
Operating Temperature: -10°C up to + 55°C
Storage Temperature: -25°C up to + 70°C
Humidity: Relative humidity 5% up to 95% not condensing
