Fiber Port: 8 pairs, LC type port, wave-length 1310nm
One of the optical ports is a dedicated 1000M optical module, which is suitable for 1000M networks.
Fiber serial port: 8, ST type port, wave-length 850nm
6 sending, 2 receiving (Can be used as FT3 or IRIG-B)
Ethernet port: 1，100Base-TX， RJ45
USB Port: 1
GPS Port: 1 channel, GPS signal receiver internal
Analog input port(Optional): 4 or 8 pairs, 18 bit AD, 40kHz sampling rate, input range 0-250VAC
Hard contact binary input: 1 Pair, Adaptive empty contact or potential contact (30~250V), response time ≤500μs
Hard contact binary output: 1 pair, Open-collect type, blocking capacity more than 250V, 0.3A (DC), response time ≤ 100μs
Measure accuracy: Voltage and current measurement accuracy error ≤0.05%
Frequency accuracy is better than 0.001Hz in the range of 15~1000Hz
Phase measurement accuracy error ≤0.01°
sending Accuracy: voltage and current measurement accuracy error ≤0.05%
Frequency accuracy is better than 0.001Hz in the range of 10~1000Hz
Phase output accuracy error ≤0.01°
SV message output dispersion: ≤±80ns
Fiber serial port transfer delay: ≤100ns
SV output synchronize: Time error between Fiber port <1μs
Power Supply: Internal large capacity lithium battery pack
Power Adapter：Input 220VAC/50Hz，-20%~+20%
Output DC 15V±10%
Display: 10.4 inch high-definition capacitive LCD screen (touch screen)
Size: 320mm×250mm×100mm(L×W×H)
Weight: <2.75kg
