AC current source
Amplitude & Power: 6×35A @ 885VA max each;
3×70A @ 170VA max each;
Accuracy: <0.015%Rd+0.005%Rg Typ
<0.04%Rd+0.01%Rg Guar.
Range:
Range I: 3A
Range II: 35A
Automatic Range
DC Offset: <3mA Typ./ <10mA Guar
Resolution: 1mA
Distortion: <0.025%Typ. / <0.07% Guar.
Ascends/Descent response: <100us
DC Current source
Amplitude & Power: 6x100A @ 50W max
Accuracy: ±5mA @ <1A
±0.2% @ ≥1A
Ascends/Descent response: <100us
AC voltage source
Amplitude & Power: 6×300V @ 65VA max each
Accuracy: ±2mV @ <2V
<0.015%Rd+0.005Rg Typ. @ 2~300V
<0.04%Rd+0.01Rg Guar. @ 2~300V
Range:
Range I: 30V
Range II: 300V
Automatic Range
DC Offset: <10mV Typ./ <60mV Guar
Resolution: 1mV
Distortion: <0.015%Typ. / <0.05% Guar.
Ascends/Descent response: <100us
DC Voltage source
Amplitude & Power: 6×150V @ 42W max
1x300V @ 885W max
Accuracy: ±10mV @ <5V
±0.2% @ ≥5V
Ascends/Descent response: <100us
Frequency & Phase Angle
Frequency Range: DC ~ 1000Hz, 3000Hz transient
Frequency Accuracy: ±0.5ppm
Frequency Resolution: 0.001Hz
Phase Range: -360°~360°
Phase Accuracy: <0.02° Typ. / <0.1° Guar. 50/60Hz
Phase Resolution: 0.001°
Binary input
Electrical isolation: 88 pairs of electrical isolated each
Input impedance: 5 kΩ…13kΩ（Empty contact）
Input feature: 0 V～300Vdc Or dry contact
(Binary inputs turn over potential can be programmable)
Sampling Rate: 10kHz
Time resolution: 10us
Time measurement range: 0～10⁵s
Time accuracy: ±1ms @ <1s
±0.1% @ ≥1s
Debounce time: 0~25ms (Software controlled)
Binary Output
Quantity: 4 pairs, Fast speed
Type: Banana type 4.0 mm
AC break capacity: Vmax：250V（AC）/ Imax：0.5A
DC break capacity: Vmax：250V（DC）/ Imax：0.5A
Electrical isolation: All pairs isolated
Synchronization port
Satellite synchronization: 1 × SMA， Use for GPS antenna interface
Support GPS and Beidou Satellite
Fiber IRIG-B: 2 × ST，1 for transmission, 1 for receiving
Electric IRIG-B: 1 × 6Pin 5.08mm phoenix terminal
1 for transmission, 1 for receiving
External trigger synchronization: 1 × 4Pin 5.08mm phoenix terminal external trigger input + external trigger output
Communication interface
Ethernet: 1 × RJ45 ，10/100M
WIFI: Inbuilt WIFI DHCP service
Serial port: 1 × RS232
USB: 2 × USB2
Weight & Size
Size: 390mm×256mm×140mm
Weight: 10kg
Display: 9.7inch LCD, touch screen
Keypad: Number key + direction key
Power supply
Nominal voltage: 220V/110V (AC)
Allowable voltage: 85 - 265 VAC ;127V～350V(DC)
Nominal Frequency: 50Hz
Allowable Frequency: 47-63Hz
Current: 10A max
Power Consumption: 1200VA max
Connection Type: Standard AC socket 60320
Working environment
Operating temperature: -10～+55 ℃
Relative humidity: 5～95%，Non-condensation
Storage temperature: -20℃ ~ +70℃
Atmospheric pressure: 80kPa～110 kPa（altitude 2000m or lower）
