KINGPO Auto-4030 ເຄື່ອງວັດຂະໜາດຮູບພາບແບບແອບຕິກດ້ວຍການຄວບຄຸມໂປຣແກຣມ CNC (30X~180X, 400x300x200mm)

(X,Y,Z)Measuring travel (mm): 400*300*200

Demo-parts weight: 30kgs

Z axis trip: 200mm

Operation: Program control CNC

Base material: Precision Granite

Body material: X,Y Precision Granite

Kind of drive: Ball screw&linear rail

Linear accuracy: 3+L/200μm(temperature 20℃±1) relative humidity:55-65%

Repeat accuracy: <3μm

Linear scales: Europe and United imported linear scales1μm(optionally equipped with: 0.5μm/ 0.1μm)

Imaging system: Europe and United high resolution color system

Light source: High brightness

Light source system: Automatic control (16 area table light/contour/coaxial light)

Optical lens: Automatic change lens

Optical power: 30X~180X

Software: AQ-6500 auto measurement software

Hardware: PC+LCD color monitor

Appearance(W*D*H): 800*900*1000

Machine weight(kgs): 250

Power: AC110V~AC220V single phase 50/60Hz
