- Input:
Voltage: 85 V to 132 V /170 V to 250 V (1 phase, 2-wire)
Frequency: 47Hz to 63Hz
Max current: 11.3 A, 5.5 A
- AC mode output ratings (AC rms)
Voltage: 1 V to 150 V / 2 V to 300 V
Voltage setting range: 0 V to 152.5 V / 0 V to 305.0 V
Voltage setting accuracy: ± (0.3 % of set + 0.6 V)
Max. current: 5 A, 2.5 A
Power capacity: 500 VA
Frequency: 1 Hz to 999.9 Hz
DC mode output ratings:
Voltage: ±1.4 V to ±212 V / ±2.8 V to ±424 V
Voltage setting range: -215.0 V to +215.5 V / -431.0 V to +431.0 V
Voltage setting accuracy: ±(0.05 % of set + 0.05/0.1 V)
Max. current: 3.5 A, 1.75 A
Power capacity: 350 W
- Output Voltage Stability:
Line regulation: Within ±0.1 %
Load regulation: Within ±0.1 V, within ±0.2 V
Ripple noise: ≤ 0.15 Vrms
- Interfaces: RS232C, USB (Option) , LAN (Option) , GPIB (Option)
- Measurement: A, V, W
- Protection Functions: Output overvoltage protection AC/AC+DC/ DC mode, Output undervoltage protection AC/AC+DC/ DC mode, Frequency Upper/Lower limit,...
- Accessories: Power cord, Setup guide, Quick Reference, Safety information, CD-ROM
(User's manual)
