- Nominal input rating: 100 V to 120 V / 200 V to 240 V, 50 Hz / 60 Hz, single phase
- Output rating for AC mode:
Rated voltage range: 1 V to135 V / 2 V to 270 V
Input voltage range: 0 V to 137.5 V / 0 V to 275 V
Voltage setting accuracy: ± (1 % of set + 0.6 V/1.2 V)
Output phase: Single phase
Maximum current: 20 A / 10 A
Power capacity: 4000 VA
Frequency setting range: 40 Hz to 500 Hz
- Output rating for DC mode:
Rated voltage range: 1.4 V to 190 V / 2.8 V to 380 V
Maximum current: 32 A / 16 A
Power capacity: 3200 W
- Output voltage stability:
Ripple noise: 0.7 Vrms / 1.4 Vrms
Output voltage response time: 150µs
Measured value display: Voltage, Current, Power
- Interfaces: RS232C, USB (option), GPIB (option)
- Accessories: Power cord, Ferrite core, Cable tie, CD-ROM
