KEYSIGHT U2055XA ຊ່ວງໄດນາມິກກວ້າງ ເຊັນເຊີພະລັງງານສະເລ່ຍ (USB type, −70 ~ +20 dBm)
ຜູ້ຜະລິດ: KEYSIGHT Model: U2055XA - ຕິດຕໍ່ພົວພັນ
Frequency Range:
10 MHz to 50 GHz
10 MHz to 53 GHz (Option 053)
Power range:
−70 to +20 dBm (10 MHz to 50 GHz)
−70 to 0 dBm (> 50 GHz to 53 GHz) (Option 053)
Connector type: 2.4 mm (male)
Maximum power
Average: +26 dBm
Peak: +29 dBm for < 10 µs duration
Voltage: ≤ 10 VDC
Zero and calibration: Internal zero and calibration supported
Maximum sampling rate: 20 Msamples/second, continuous sampling
Single shot bandwidth: 5 MHz
Minimum pulse width: 250 ns
Rise/fall time: ≤ 100 ns
Maximum capture length:
1 s (decimated)
6.5 ms (at full sampling rate)
Maximum pulse repetition rate: 2 MHz (based on 10 samples/period)
