Frequency range: 50 MHz to 18 GHz
Power range:
Normal mode
–30 dBm to 20 dBm (50 MHz to <500 MHz)
–35 dBm to 20 dBm (500 MHz to 40 GHz)
–35 dBm to 8 dBm (> 40 GHz to 50 GHz)
Average only mode
–45 dBm to 20 dBm (50 MHz to 40 GHz)
–45 dBm to 8 dBm (> 40 GHz to 50 GHz)
Connector type: N-type (m)
Inputs/Outputs
Current requirement: 450 mA max (approximately)
Recorder output: Analog 0 to 1 V, 1 kΩ output impedance, SMB connector
Video output: 0 to 1 V, 50 Ω output impedance, SMB connector
Trigger input: Input has TTL compatible logic levels and uses a SMB connector
Trigger output: Output provides TTL compatible logic levels and uses a SMB connector
Remote programming
Interface: USB 2.0 interface USB-TMC compliance
Command language: SCPI standard interface commands, IVI-COM, IVI-C driver and LabVIEW drivers
Maximum measurement speed
Free run trigger measurement: 25,000 readings per second 1
External trigger time-gated measurement: 20,000 readings per second
Standard shipped Items
– Power sensor cable 5 ft (1.5 m), default cable length
– BNC male to SMB female trigger cable, 50 Ω, 1.5 m (Quantity: 2)
– Certificate of calibration
