Number of Channels: 5
Number of Slots: 1
Output Range:
Maximum Voltage: 30V
Maximum Current (DC): 500mA
Maximum Current (Pulse): 500mA
Resolution:
Minimum Voltage: 6uV
Minimum Current: 10pA
RMS Current Measurement Noise (1 PLC): 35pArms
Voltage Source Noise:
Peak-to-peak (0.1 - 10 Hz): < 20μV
Peak-to-peak (20 MHz): < 12mV
RMS (20 MHz): < 1mVrms (< 25μVrms with PX0107A)
RMS (200 MHz): < 3.3mVrms
Minimum Pulse Width: 100μs
Maximum Voltage Ramp Rate: 0.15V/μs
Digital Mode: Available
Maximum Sampling Rate: 500 kSa/s
Automatic Range: Available
Automatic Continuous Current Range: Available
Remote Connection (4-Wire Connection): Available
Low-Current Measurement Protection Port: Available
Operating Modes:
Standard Mode: Available
PS Mode: Available
High Capacitance Mode: Not available
Laser Mode: Not available
Environmental Specifications:
Temperature: 0°C ± 50°C
Humidity: 10% to 80%
Warm-up Time: 40 minutes
Self-Calibration: Performed within 24 hours
Temperature Change During Self-Calibration: Less than ±5°C
Calibration period: One year
Aperture Time: 1 PLC
Terminal Connection: Kelvin Connection.
