Number of channels: 5
Number of slots: 1
Output range
Max. voltage: 30V
Max. current (DC): 500 mA
Max. current (Pulse): N/A
Resolution Min. voltage: 6 uV
Min. current: 100 pA
Current measurement noise RMS (1 PLC): 75 pArms
Voltage source noise
Peak-to-peak (0.1 - 10 Hz): < 20μV
Peak-to-peak (20 MHz): < 12 mV
RMS (20 MHz): < 1 mVrms (< 25 μVrms with PX0107A)
RMS (200 MHz): < 3.3 mVrms
Min. pulse width: N/A
Max. slew rate: 0.15 V/μs
Digitizer mode: No
Max. sampling rate: 250 kSa/s
Auto measurement ranging: Yes
Seamless current measurement ranging: Yes
Remote sense (4-wire connection): Yes
Guard shield port for low current measurement: Yes
Operation mode
Standard mode: Yes
PS mode: Yes
High capacitance mode: No
Laser diode mode: No
Temperature: 0°C ± 50°C
Humidity: 10% to 80%
Warm-up time: 40 minutes
Self-calibration: Performed within the last 24 hours.
Ambient temperature changes less than ± 5 °C after self-calibration execution.
Calibration period: One year
Aperture time: 1 PLC
Terminal connection: Kelvin connection
