Power Output: 800W
No. of Channel: 1
DC Output Rating (0 to 40 °C): 0 to 30 V; 0 to 80 A
Load Regulation ± (% of output + offset):
+ Voltage : < 0.01% + 2 mV
+ Current : < 0.1% + 2 mA
Line Regulation ± (% of output + offset):
+ Voltage : < 0.01% + 2 mV
+ Current : < 0.1% + 2 mA
Output Ripple and Noise (at approximately 23 °C):
+ Normal mode voltage, Vpp (20 Hz to 20 MHz): < 75 mV
+ Normal mode voltage*, Vrms (20 Hz to 10 MHz): < 7.5 mV *
Programming Accuracy ± (% of output + offset) at 23 °C ± 5 °C for 12 months.:
+ Voltage : 0.03% + 6 mV
+ Current : 0.1% + 20 mA
Readback Accuracy ± (% of output + offset) at 23 °C ± 5 °C for 12 months.:
+ Voltage : 0.04% + 6 mV
+ Current: 0.1% + 20 mA
+ Low Range Current: 0.1% + 5 mA
Load Transient Recovery Time (Time to recover within the settling band following a load change from 50% to 100%; and from 100% to 50% of full load):
+ Voltage Settling Band : 75 mV
+ Time : < 1 ms
Programming Resolution (Remote):
+ Voltage: 2 mV
+ Current : 5 mA
Readback Resolution (Remote):
+ Voltage : 1 mV
+ Current: 3 mA
+ Low Range Current1 : 50 µA
Programming Resolution (Front Panel):
+ Voltage : 1 mV
+ Current : 1 mA
Readback Resolution (Front Panel):
+ Voltage: 1 mV
+ Current : 1 mA
+ Low Range Current1 : 100 µA
Output Ripple and Noise (20 Hz to 10 MHz):
+ Normal Mode Current : < 1 mArms
Overvoltage Protection (OVP) ± (% of output + offset):
+ Programming Accuracy: 0.2% + 0.4 V
Activation Time (Average time for the output to start dropping after OVP and OCP condition occurs):
+ Overvoltage (OVP) : < 5 ms
+ Overcurrent (OCP) : < 5 ms
+ Command Processing Time: < 10 ms
Programming Temperature Coefficient per °C (% of output + offset):
+ Voltage: 0.005% + 0.5 mV
+ Current: 0.01% + 1 mA
Readback Temperature Coefficient per °C (% of output + offset):
+ Voltage: 0.005% + 0.5 mV
+ Current : 0.01% + 1 mA
Remote Sense (Maximum voltage in load lead): 0.7 V
Environmental Conditions:
Operating environment: Indoor use, installation category II (for AC input), pollution degree 2
Operating temperature range: 0 to 40 °C
Storage temperature: –20 to 70 °C
Relative humidity : 80% RH at temperature up to 40 °C, non-condensing
Altitude : Up to 2000 meters
AC input : ~100 - 230 VAC (±10%), 50/60 Hz, <1300VA
