Alarms
Analog inputs: Hi, Lo, or Hi + Lo evaluated each scan
Digital inputs
34950A/52A digital in maskable pattern match or state change
34950A/52A frequency and totalize: Hi limit only
Monitor channel: Alarm evaluated each reading
Alarm outputs: 4 TTL compatible. Selectable TTL logic Hi or Lo on fail
Latency: 5 ms (typical)
Memory
Type: Volatile
Readings: 500,000 with timestamp, readable during scan
Line power
Power supply: Universal 100 V to 240 V ± 10%
Power line frequency: 50 – 60 Hz ±10% automatically sensed
Power consumption: 150 VA
Environment
Operating environment: Full accuracy for 0 °C to 55 °C
Storage environment - 40°C to 70°C 1
Mechanical
Mainframe dimensions
133 H x 426 W x 341 D mm (5.25" x 16.8" x 14")
Full rack, 3 units high
Mainframe weight: 8.8 kg (19.6 lbs)
