Bandwidth: 50 MHz
Analog channels: 2 + 1 (ext. trigger viewable as digital channel)
External trigger (or 3rd digital channel): 1
Maximum sample rate 1 GSa/s (all channels)
Maximum memory depth: 200,000 points (all channels)
Waveform update rate: 100,000 waveforms per second
WaveGen: 20-MHz function generator
Bode plot: Standard
Serial protocol analysis: Standard: I²C, UART/RS-232
Waveform math: Add, subtract, multiply, divide, FFT (magnitude and phase), low pass filter
Automatic measurements: 14 amplitude, 14 timing, and 4 pulse count measurements
Display: 7-inch TFT LCD WVGA
Connectivity: USB 2.0 (host and device), LAN
Dimensions (W x H x D): 314 mm (12.4 in) x 165 mm (6.5 in) x 130 mm (5.1 in)
Weight Net: 3.23 kg (7.1 lbs), shipping: 4.2 kg (9.2 lbs)
