Electrical specifications:
Load Rated Voltage: Single phase 2-wire 100V, single phase 2-wire 200V, single phase 3-wire 200V
Load circuit configuration: 10W x 2, 20W x 2, 40W x 1, 100W x 1, 200W x 2, 400W x 1, 1kW x 1, 2kW x 1
resistance error: ±10%
load capacity: 6kW
Rating: continuous
Load Settings: Switch-on type
Control power supply: Single-phase 2-wire AC100V Maximum current approx. 1.4A
Location: indoor
Control Voltage: Single phase, two-wire 100Vrms (1.4Arms)
General Specifications:
External dimensions (excluding protrusions): W430×H268×D600
Mass: Approx. 22kg
Insulation resistance: Between load terminal and case: DC500V 10MΩ or more; Between FAN power input terminal and case: DC500V 10MΩ or more
Withstand voltage: Between load terminal and case: AC2kV for 1 minute; Between fan power input terminal and case: AC1.5kV for 1 minute
Usage environment: Installation location: Indoors Temperature and humidity: 5 to 40°C, 20 to 80% RH or less (no condensation)
others: Cooling method: Forced air cooling Paint color: 5Y7/1 Semi-gloss
