Performance Data Temperature
Temperature range 10 °C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 2.5
Temperature fluctuation [± K]: 0.8
Heating-up time to 150 °C [min]: 20
Recovery time after 30 seconds door open at 150 °C [min]: 12
Air change data
Air circulation (approx.) [x/min]: 20
Volumetric flow rate of exhaust air acc. to EN 1539 at 50 °C [ca. L/min]: 400
solvent quantity
Highest permitted solvent quantity (at T-180 °C, M-100g/mol, U-40g/m3, K=0,5) [g]: 66.5
Electrical data
Rated Voltage [V]: 230
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 2.9
Phase (Nominal voltage) [ph]: 1~
Outer dimensions
Width net [mm]: 830
Height net [mm]: 805
Depth net [mm]: 685
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Internal Dimensions
Width [mm]: 600
Height [mm]: 435
Depth [mm]: 435
Further Dimension
Interior volume [L]: 115
Net weight of the unit (empty) [kg]: 90
permitted load [kg]: 60
Load per rack [kg]: 30
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 1200
Sound-pressure level [dB(A)]: 57
Fixtures
Number of shelves (std./max.): 2 / 5
