Manufacturer: Kanomax
Model: 3718-A
Origin: Japan
Warranty: 12 months
- Particle Size Distribution: 0.3μm, 0.5μm
- Rated Flow: 28.3L/min (1CFM)
- Optical Source: Laser Diode
- Counting Efficiency: Compliant with ISO21501-4, JIS B 9921
- Max Detectable Concentration: 500,000CNT/ft3
- Setting Parameter:
+ Sampling Time: 1 to 60 seconds
+ Output Range Setting (To be configured for each particle size)
Count: 0-10CNT, 0-100CNT, 0-1,000CNT, 0-10,000CNT
Concentration: 0-10CNT/cf, 0-100CNT/cf, 0-1,000CNT/cf,
0-1,000,000CNT/cf
0-353CNT/ m3, 0-3,530CNT/m3,
0-35,300CNT/m3, 0-35,300,000CNT/m3
+ Alarm Setting: 0%-100%
+ Address Setting: 0-512
+ Error Output Setting: ON/OFF
- Sampling Pump: External vacuum>51kPa
- Interface: RS485, Analog Output (4-20mA)
- Communication: RS485
- Setting Software: Japanese, English
- Power Supply:
1.) DC Power Supply: DC 9V-28V
2.) AC Adapter: AC 100-240V (50-60Hz), DC 12V
- Operating Environment: 10~30°C, 20~85%RH (Non-condensing)
- Storing Environment: Temperature: -10 to 50°C, Humidity: 95%RH or less (Non-condensing)
- Dimension: 133mm (W) × 95mm (D)× 80mm (H)
- Weight: 1.0kg
- Standard Accessories: User’s Manual (English)(1), User’s Manual (Japanese) (1), AC adapter (1), Zero Filter (1), Adapter 1
(1), Adapter 2 (1), Tygon Tube 1 (1), Setting Software DVD - 3718/19-40 (1)
- Optional Accessories:
USB-RS485 Converter 3716A-20 (Converter + Converter Connecting Cable), Converter
Connecting Cable 3716A-21, RS232c-RS485 Converter 3716A-22 (Converter + Converter
Connecting Cable), Isokinetic Probe - 3905-07 (1), Isokinetic Suction Probe 3718-01 (1), Tygon
Tube 1 (1), Tygon Tube 2 (1)
- Features:
2-channel particle sensor with Modbus communication via RS485 interface
Flexible 4-20mA analog output (1.0 cfm unit only)
0.1 cfm and 1.0 cfm flow rates are available
Outputs particle counts, error status and alarm signal
Able to connect to a PLC or data logger for facility monitoring applications
Can be added to a process or building automation system
Fully compliant with ISO21501-4 calibration standard and JIS B9921
Configuration software is included for easy user parameter setup
Power can be provided via a network connection or AC adaptor
Stainless steel housing
3-year warranty included
- Applications:
Cleanroom Facility Monitoring
Food Industry
Aerospace
Hospital Surgical Rooms
