- Wideband:
+ Input Frequency Range: 10MHz – 14000MHz (14.0GHz)
+ Sensitivity:
100MHz -49 dBm
200MHz -48 dBm
500MHz -47 dBm
1GHz -44 dBm
2GHz -50 dBm
5GHz -42 dBm
10Ghz -30 dBm
14Ghz -2 dBm
- Cellular Bands:
+ 4G 800MHz:
Band Width: 824 – 849 MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -60dBm
+ 2G 900MHz:
Band Width: 880 - 915MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -52dBm
+ 2G/4G 1800MHz:
Band Width: 1710 - 1785MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -52dBm
+ 3G (UMTS) (WCDMA) 2100 MHz:
Band Width: 1925 - 1975MHz
Out-of-Band Attn: > 70dB
Min. Detection Level: -76dBm
+ 4G 2600MHz:
Band Width: 2500 – 2570 MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -53dBm
- 2.4 & 5 GHz Wireless Bands:
+ 2400MHz WIFI/BLUETOOTH etc.:
Band Width: 2400 – 2485 MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -56dBm
+ 5000MHz WIFI/WLAN etc.:
Band Width: 4900 to 5950MHz
Out-of-Band Attn: >40dB typ
Min. Detection Level: -52dBm
-Display: TFT Colour 3.5’ High Contrast Graphic Display
-Battery:
Internal Li-Ion rechargeable
Operating Duration – fully charged battery 8 hours
Charge Time – 4 hours
-Operating Temperature Range: -15 to +50 degrees C - Relative Humidity < 90%
-Dimensions: 186mm x 195mm x 34mm (max)
-Weight: 600 g – Main Unit
-Signal Processing and Control: RISC Based Microcontroller with real time clock
-Event Log: Maximum 4000 Events
-USB Socket: For USB Stick Event Log download only
SUPPLIED ACCESSORIES
+ Flexible Multiband Whip Antenna Long (Wideband)
+ Flexible Cellular Antenna (Medium)
+ Rigid 2.4 GHz & 5 GHz Antenna (Short)
+ Directional High Gain Antenna – LPA14
+ 5V DC Charger - 110V to 240V AC input (Auto Switching)
with International Adaptors
+ USB Memory Stick with Data Viewer Software for Windows
based computers.
+ Earphones
+ High Protection Military Standard Carry Case
