Maximum Load: 500N (50kgf)
Auto Switch Over of Hi / Lo Range: 50kN/5kN
Load Resolution: 0.01N (1gf）
Load Accuracy: JIS B 7738 Class 0.5 ( ± 0.5% of Applied Load)
Maximum Free Length to test: 77mm
Length Resolution: 0.01mm
Length Accuracy: ± (0.05 + 0.0001 * L) mm where L is the arbitrary length
Test Speed: 1~1000mm/min
Max test length: 180mm
Maximum O.D of Spring for test: Ø36mm
Cycle Time of Testing: About 50 pcs/min (depend on stroke...)
Power Supply: Single Phase AC 110 ~120V or AC 220~240V (50/60Hz)
Power Rating: 300VA
Dimension: W520 x D660 x H1354mm
Weight: Approx 180 kg
CHARACTERISTICS
ACE series Fully Automatic Spring Tester withSorting function.
This tester conform to JIS B 7738 Grade 0.5 which is the highest grade.
It function is similar to our PRO Series of spring tester except that its touch screen with SPC control function to show Histogram & Trend Chart.
There are only 2 models for this series, ACE-100N & ACE-1kN only.
