Channel: dual channel
Input rating:
Voltage: 0~150V
Current: 0~2A, 0~20A
Power: 2x200W
CV mode:
Range: 0~18V, 0~150V
Resolution ratio: 1mV, 10mV
Precision: ±(0.05%+0.025%FS)
CC mode:
Range: 0~2A, 0~20A
Resolution ratio: 1mA, 10mA
Precision: ±(0.05%+0.05%FS)
CR mode:
Range: 0.05Ω-7.5ΚΩ
Resolution ratio: 16 bit
Precision: 0.1% +0.5%FS
CP mode:
Range: 200W
Resolution ratio: 10mW
Precision: 0.1% +0.5%FS
Dynamic current:
Dynamic mode (T1 & T2): 100µS~3600S
Precision: 5 µS±100 ppm
Rise/Fall slope: 0.001~0.15A/μS
Voltage read-back:
Range: 0~18V, 0~150V
Resolution ratio: 1mV, 10mV
Precision: ±(0.05%+0.1%FS)
Current read-back:
Range: 0~2A, 0~20A
Resolution ratio: 1mA, 10mA
Precision: ±(0.05%+0.1%FS)
Power read-back:
Range: 200W
Resolution ratio: 10mW
Precision: ±(0.1%+0.5%FS)
Basic protection:
Power protection: 202W
Current protection: 20.2A
Voltage protection: 152V
Temperature protection: 85℃
Size: 300mm x 88mm x 174mm
