JINKO JK824 ມືຖື LCR Digital Bridge Meter (100Hz, 120.048Hz, 1kHz)
Measurement Range:
L: 0.1μH – 999.9H
C: 0.1pF – 999.9mF
R, X, Z: 0.0001Ω – 99.99MΩ
D: 0.0001 – 9.999
Q: 0.0001 – 999.9
θd: -179.99° – 179.99°
θr: -3.1416 – 3.1416
%: -999.9% – 999.9%
Primary Parameters: C, L, R, Z, AUTO
Sub Parameters: OFF, AUTO, D, Q, ESR, θr, θ°, X
Display: 50000 readers
Basic Accuracy: 0.2%
Equivalent Mode: Serial, Parallel and AUTO
Ranging: Auto and Manual
Speed:
Slow: 1.5 times/second
Fast: 4 times/second
Test Frequency: 100Hz, 120.048Hz, 1kHz
Test Signal Level: 0.6 Vrms, Accuracy: 10%
Signal Source Resistance: 100Ω
Correction: Open and short correction
Comparator: Primary parameter percentage, Beep
Test Terminal: 5 terminals and 3 terminals
Interface: USB-HID
Features:
Display: TFT-LCD Display, 2.8 inch with touchscreen
Brightness: 30%, 50%, 70%, 100%
Power-save: Adjustable brightness and auto power off time
Power:
Battery: Rechargeable Li Battery: ATL805
AC Adapter: JKL909, 90V~250VAC, 9VDC, 1A
Max power: 0.9W
Standby Current: 50μA max
Battery Working Time:
8h @ 100% brightness
11h @ 50% brightness
14h @ 30% brightness
Charge Time: About 2h
Lower Brightness Auto Power Off: 5min/10min/20min/30min/OFF (Powered by battery)
Auto Power Off: 5min/10min/20min/30min/OFF (Powered by battery)
General:
Temperature: 0°C~40°C
Humidity: ≤ 90% RH
Altitude: 2000m
Storage Temperature: -10°C~70°C
Weight: 350g
Safety and Electromagnetic Compatibility:
IEC 61010-1:2001
IEC 61326-2-1:2005
