Measurement function
Measurement parameter:L-Q, C-D, R-Q, |Z|-Q
Basic accuracy:0.1%
Equivalent circuit:Series ,parallel
Mathematical function:Absolute value deviation,△%
Range mode:Auto, Hold
Trigger mode:Internal, Manual, External
Measurement speed:Fast: 18, Med:8,Slow: 2.5 (time/second)
Calibration function:Open/Short full correction
Measurement terminal:5-terminal
Display mode:Direct，Δ%，
Display:192*64 LCD display
Measurement signal
Signal frequency:100Hz,120Hz,1kHz,10kHz
Output impedance:30 Ω, 100 Ω
Test level:0.1Vrms, 0.3Vrms, 1Vrms
Measurement display range:
|Z|, R0.0001 Ω —99.999 MΩ
C0.01 pF —99999μF
L0.01 μH —99999 H
D0.0001 —9.9999
Q0.0001 —9999.9
Δ%-999.99% —999.99%
Comparator and interface
Comparator:NG, P1, P2, P3, 4 Bins and Alarm mode setup
Interface:RS232C, Handler (option)
General Specifications
Operation Temperature And Humidity0°C－40°C, ￡90%RH
Power supply:
voltage99V－121V, 198V－242V
frequency 47.5Hz－63Hz
Power consumption:≤20 VA
Volume (W×H×D):270mm×130mm×290mm
Weight:about 3.5kg
