Chamber Volume (L / cu ft) 420 lit
Controller Programmable, Touch screen type controller (3.5" Color monitor)
Temperature Range (℃ / ℉) :-35~180℃
Temperature Fluctuation at 25℃ (℃ / ℉) 0.2 / 0.36
Heating Time 2) (min.) from 25 to 180℃ 46
Cooling Time 2) (min.) from 25 to -70℃ 35
Heating Rate (℃ / ℉ per min.) from -50℃ to 120℃ 2.0
Cooling Rate (℃ / ℉ per min.) from 120℃ to -50℃ 2.1
Interior (mm / inch) 750×700×800 mm
Exterior (mm / inch 1140×1380×1590 mm
Net Weight (kg / lbs) 320 kg
Interface Port Basically RS-232C [RS-485(Maximum 32 Units Control)-optional]
Electrical Requirements (380V, 50Hz) 3ph / 12.5A , Cat. No. AAHKB038K
| Description | No. |
|---|---|
| Programmable Pattern Capacity | 100 |
| Pattern Repeat Time | 999 |
| Part repeat time | 255 |
| Max. Segments per a Pattern | 100 |
| Available Max. Segments* | 6000 |
| Programmable Process Time per a Segment | 0 to 99 hr 59 min |
| Model | JMV-012 | JMV-025 | JMV-040 | JMV-070 | JMV-100 | |
|---|---|---|---|---|---|---|
| Chamber Volume (L / cu ft) | 125 / 4.4 | 253 / 8.9 | 420 / 14.8 | 720 / 25.4 | 1000 / 35.3 | |
| Controller | Programmable, Touch screen type controller (3.5" Color monitor) | |||||
| Temperature Range (℃ / ℉) | -35 to 180 / -31 to 356 | |||||
| Temperature Fluctuation 1) 2) at 25℃ (℃ / ℉) |
0.5 / 0.9 | 0.5 / 0.9 | 0.3 / 0.54 | 0.4 / 0.72 | 0.3 / 0.54 | |
| Temperature Variation 2) (±℃ / ℉) |
at -35℃ | 0.7 / 1.26 | 0.7 / 1.26 | 0.5 / 0.9 | 1.0 / 1.8 | 0.7 / 1.26 |
| at -25℃ | 0.7 / 1.26 | 0.7 / 1.26 | 0.6 / 1.08 | 1.1 / 1.98 | 0.8 / 1.44 | |
| at -10℃ | 0.8 / 1.44 | 0.8 / 1.44 | 0.6 / 1.08 | 1.2 / 2.16 | 0.9 / 1.62 | |
| at 25℃ | 0.8 / 1.44 | 0.8 / 1.44 | 0.5 / 0.9 | 0.8 / 1.44 | 0.9 / 1.62 | |
| at 70℃ | 0.9 / 1.62 | 0.9 / 1.62 | 0.7 / 1.26 | 1.2 / 2.16 | 0.8 / 1.44 | |
| at 100℃ | 1.0 / 1.8 | 1.0 / 1.8 | 0.8 / 1.44 | 1.2 / 2.16 | 0.9 / 1.62 | |
| at 150℃ | 1.2 / 2.16 | 1.2 / 2.16 | 1.3 / 2.34 | 1.1 / 1.98 | 1.1 / 1.98 | |
| at 180℃ | 1.4 / 2.52 | 1.4 / 2.52 | 1.5 / 2.7 | 1.3 / 2.34 | 1.4 / 2.52 | |
| Heating Time 2) (min.) from 25 to 180℃ | 67 | 67 | 46 | 44 | 60 | |
| Cooling Time 2) (min.) from 25 to -35℃ | 48 | 48 | 35 | 35 | 58 | |
| Recovery time 2) after door was opened (min.) |
at -35℃ | 6.0 | 6.0 | 6.0 | 6.5 | 9.0 |
| at -25℃ | 5.0 | 5.0 | 6.5 | 7.0 | 6.5 | |
| at -10℃ | 6.5 | 6.5 | 6.5 | 8.5 | 6.5 | |
| at 25℃ | 5.5 | 5.5 | 4.5 | 2.0 | 7.0 | |
| at 70℃ | 8.5 | 8.5 | 8.0 | 9.5 | 7.5 | |
| at 100℃ | 5.5 | 5.5 | 4.5 | 6.0 | 5.5 | |
| at 150℃ | 6.5 | 6.5 | 7.0 | 9.0 | 3.5 | |
| at 180℃ | 6.5 | 6.5 | 6.5 | 8.0 | 4.0 | |
