Function: Wire cutting, Single / Dual-end strip and twist, Single / Dual-end crimp, Cut depth, Pull-off length, Insulated terminal, non-insulated terminal, etc.
Wire cross-section: 0.1-2 mm² (AWG 28-14) [can be custom]
Strip length: 1.5-10 mm
Cut length (L): 45-99999 mm
Cut length tolerance: ±1mm + 0.002 x L
Crimp force: 20KN (2.0 tons) [40 KN on request] [Servo model]
Detector: Wire lack, Terminal crimping, Wire knot, Air pressure [CFM on request]
Production rate: 900-10000 pcs/h by 100 mm wire length, insulated terminal
Display: 7" touch screen, English / Chinese [other languages on request]
Power supply: AC 110-220V ± 10%, 50/60 Hz
Air supply: 0.4-0.6 MPa [Clean and dry air]
Weight: 430 KG
Dimensions: L 1100 x W 900 x H 1500mm Straightener: 800 mm
CE-Conformity: Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
• Crimping all kinds of bulk terminals automatically
• All insulated terminal and non-insulated terminals can be processed
• Brand new design, fully covered safety guard, interlock sensor on request
• Servo model crimping press located terminals before crimping
