JCW JCW-CS07C Servo Motorized Belt Feed 16mm OD ສາຍແບດເຕີລີ່ OD ເຄື່ອງຕັດແລະສາຍ (50 mm², 0.1-999999 mm)
Function: Multicore cable, Single wire, Wire measuring, Cut into length, Full stripping, Partial stripping, Wire lack sensor, Length correction, Safety cover sensor
Conductor cross-sections: O.D. 16 mm, Max 50 mm² [AWG0] /
Cutting length (L): 0.1-999999 mm
Cutting length accuracy: 0.002 x L
Production rate: 1300 pcs/h
Stripping length:
Leading (right) side: 400 mm [partial stripping]
Trailing (left) side: 180 mm [partial stripping]
Display: 7" color touchscreen, English / Chinese [other languages on request]
Feeding unit: Servo motorized belt system
Power supply: AC 110V-220V±10%, 50/60 Hz
Cutting unit: Servo motorized cutter head
Dimensions: L 830 x W 570 x H 470 mm
Weight: 95KG
