Function: Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc
Conductor cross-sections: 0.1 - 25 mm², 12 mm diameter
Cutting length (L): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length:
Front (right) side: 250 mm [partial stripping]
Rear (left) side: 120 mm [partial stripping]
Middle strip: 13 sections
Production rate: 1000 pcs/h by 100 mm wire length
Data library: 100 programs
Flat cable: Slit and strip, by changing straightener, guide, and blade
Multicore cable: Outer jacket stripping
Display: 7" color touchscreen, English / Chinese [other languages on request]
Cable feeding: 8 rollers
Compatible peripherals: Cable prefeeding machine, robot arm, conveyor belt
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions: Machine: L 650 x W 580 x H 450 mm
Weight: 70 kg
• Special model for multi-mid-stripping
• 4th generation powerful and precise cut & strip machine
• AV battery cable, multiconductor cable
• PVC, Teflon, Silicone, Low halogen, Fiberglass cables
• Cable range up to 12mm O.D or 25sqmm
• 7" color touch screen, user-friendly interface
• 8 rollers driven by high torque hybrid step motors
• Fully programmable saves 100 programs
