JCW JCW-CS02 ECO ເຄື່ອງປ່ຽງສາຍອັດຕະໂນມັດແບບປະຢັດ (0.03-4 mm², 0.1 - 999999 mm)

Function: Wire measuring, Cut into length, Full stripping, Partial stripping, Middle strip, Length correction

Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass

Conductor cross-sections: 0.03-4 mm²

Cutting length ( L ): 0.1 - 999999 mm

Cutting length accuracy: 0.002 x L

Stripping length: Front (right) side - 50 mm [Full stripping], Rear (left) side - 30 mm [Full stripping]

Production rate: 4100 pcs/h by 100 mm wire length

Data library: 100 programs

Display: 4.3" color touchscreen, English / Chinese [Other languages on request]

Compatible peripherals: Wire prefeeder, robot arm, conveyor belt

Wire feeding: Metal roller [Urethane roller on request]

Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz

Air supply: 0.4 - 0.7 MPa (clean and dry air)

Dimensions: Machine - L 370 x W 400 x H 300 mm, Straightener - 150 mm

Weight: 22 KG

CE-Conformity: Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.

• Thin lead wire, short stripping

• Wire range up top 4mm²

• Best price, good performance

• Touch screen, English display

• Best choice for low-budget customers

• No safety cover

Video
