Peak power: 300W (230V)
Selectable temperature: 50 to 250 ºC / 120 to 482 ºF
Heating area 180 x 277 mm / 7.1 x 10.9 in - 1 zone
Type K TC connector: 2 for Control & Protection
Profiles: 22 (up to 16 steps for each)
Set temperature profiles: 3 profiles (2, 3 or 4 steps)
Maximum work time: 50 min or indefinite
ESD safe: Meet ANSI/ESD S20.20-2021
USB-A: Firmware update/ Graphics and profiles
USB-B: PC communications
Robot connector: Remote control
Aux. connector: Console connection
Pedal connector: Connect a pedal (ref. P-005) to control the heater
Weight and dimensions
310 x 239 x 205 mm / 7.60 kg.
12.20 x 9.41 x 8.07 in / 16.75 lb.
PRODUCT COMPOSITION
1 Instruction Manual
1 PHNE Preheater for PCBs up to 11 x 7 cm / 4 x 3 in
1 PHNS Support for PCBs up to 11 x 7 cm / 4 x 3"
1 RHN Articulated Hand Rest for PHNEK Preheater Set
