JASIC LS-20000F ເຄື່ອງເຊື່ອມເລເຊີ (ລຸ້ນທີ 3) (1080 ± 10nm, 0.5-6mm)

Power supply: AC220V±10%/50HZ

Power: 2000w

Total power consumption: 7.8Kw

Laser wavelength: 1080 ± 10nm

Welding laser beam width: 0-6mm

Welding material thickness: 0.5-6mm

Welding wire diameter: 0.8/1.0/1.2/1.6

Maximum width of welding gap: ≤ Diameter of welding wire

Recommended cutting thickness: 5mm

Cleaning speed: 50mm/s

Cleaning width: 0-120

Machine weight: 92 kg

Machine dimensions: 773*410*737mm

Wire feeder weight: 11.5 kg

Wire feeder dimensions: 628*240*340mm

Coolant tank capacity: 8L

Protective gas: Argon/Nitogen

Operating temperature: -10°C- 40°C

Standard accessories:

Laser source: 2000W – JASIC

Cooler

Controller, Welding gun: SUP23T

Wire feeder: WF-22L
