Fall Time: 10 ns
Rise Time: 20 ns
Technology: Si
Unit Weight: 6.500 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: Through Hole
Transistor Type: 2 N-Channel
Qg - Gate Charge: 190 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 480 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 30 ns
Typical Turn-Off Delay Time: 100 ns
Id - Continuous Drain Current: 47 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 45 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
