Width: 10.2 mm
Height: 4.7 mm
Length: 9.4 mm
Fall Time: 24 ns
Rise Time: 27 ns
Technology: Si
Unit Weight: 1.600 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 140 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 480 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 20 ns
Typical Turn-Off Delay Time: 36 ns
Id - Continuous Drain Current: 260 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 55 S
Rds On - Drain-Source Resistance: 3.3 mOhms
Vds - Drain-Source Breakdown Voltage: 55 V
Vgs th - Gate-Source Threshold Voltage: 4 V
