IWINTESTING U910 ເຄື່ອງກວດຈັບອັລຕຣາໂຊນິກຄອນກີດ (0–10 mm)

Master Control Unit: Built-in A8 industrial control motherboard

Display: 10.1-inch, high-brightness TFT color LCD capacitive touchscreen

Operational Mode: Touch screen

Storage Mode: Built-in electronic hard disk (>8 GB) + large-capacity USB flash drive

Data Transmission Mode: Wireless cloud transmission (optional)

Acquisition Mode: Single-channel manual point-by-point acquisition

Number of Disposable Profiles: –

Channel Number: 1 transmit + 1 receive

Trigger Mode: Signal triggering

Sampling Period (μs): 0.05–409.6, multi-stage options

Acoustic Time Accuracy (μs): 0.05

Acoustic Time Range (μs): 1,677,700

Width Measurement Function: Measuring range: 0–10 mm; Measurement accuracy: 0.01 mm

Dynamic Range (dB): 146

Bandwidth (kHz): 1–500

Receiving Sensitivity (μV): <10

Gain Accuracy (dB): 0.5

Emission Voltage (V): 65, 250, 500 and 1,000; 4-level adjustable

Communication Interface: USB, Bluetooth, Wi-Fi

Working Hours (h): More than 8

Power Supply Mode: Built-in lithium battery; External 220 V–16 V AC/DC

Working Environment: Temperature: −10 to +40 °C; Humidity (RH): <90%

Host Size (mm): 300 × 200 × 55

Features

New upgraded wireless cloud transmission function;

Five functions of measuring pile, measuring strength, measuring defect, sounding depth and width measuring;

Stable performance and powerful function, it is the best choice for users with diverse needs such as engineering inspection, teaching and scientific research;

Semi-transparent, high-brightness, TFT color LCD screen;

Full touch screen operation, simple and convenient, stable and reliable;

Large memory capacity and working time of more than 10 hours;

It can be connected with the probe of digital display rebound instrument to measure the strength of ultrasonic rebound

U-disk transfers data and supports software upgrading through u-disk;

Special analysis software is powerful, data analysis and processing, report generation, and report printing can be completed easily.
