Rated (0~40℃)
Voltage: 0~150V
Current: 0~60A, 0~600A
Power: 6kW
Minimum operating voltage: 0.075V/60A, 0.75V600A
CV mode
Range: 0~18V, 0~150V
Resolution: 1mV, 10mV
Accuracy: ±(0.05%+0.05%FS), ±(0.05%+0.05%FS)
CC Mode
Range: 0~60A, 0~600A
Resolution: 1mA, 10mA
Accuracy: ±(0.05%+0.1%FS), ±(0.05%+0.1%FS)
CR Mode
Range: 0.0015Ω~150Ω
Accuracy: Vin/Rset *(0.2%) + 0.2% IF.S.
CP Mode
Range: 6kW
Resolution: 0.1W
Accuracy*1: 0.2%+0.2%FS
Dynamic Mode
Dynamic mode*2 CC Mode
T1＆T2: 20uS~3600S /Res:1 us/10ms/100ms
Accuracy: 5uS±100ppm
Rising/falling slope: 0.001~3A/uS, 0.01~30A/uS
Minimum rising time: ≒12uS, ≒12uS
Measuring range
Readback Voltage
Range: 0~18V, 0~150V
Resolution: 1mV, 10mV
Accuracy: ±(0.025%+0.025%FS), ±(0.025%+0.025%FS)
Readback Current
Resolution: 1mA, 10mA
Accuracy: ±(0.05%+0.1%FS), ±(0.05%+0.1%FS)
Readback Power:
Resolution: 0.1W
Accuracy*1: ±(0.2%+0.2%FS)
*1 Power F.S.=Vrange F.S. X Irange F.S.
*2 Loading current value is not less than 4%FS_CCH
*This information is subject to change without notice.
